Appendix A — Specifications
PM4i Mid-Range Printer User’s Manual 125
Tickets With Gaps (Gap Stock)
LSS Detection Position (c)
This position is variable. For help, see “Adjusting the Label Stop
Sensor” on page 99.
Detection Slit Length (d)
The length of the detection slit (excluding corner radii) must be a
minimum of 2.5 mm (0.10 in) on either side of the LSS detection
position (c).
Media Width (a)
Measurement Value
Maximum 114.3 mm (4.50 in)
Minimum 25.0 mm (1.00 in)
Copy Length (b)
Measurement Value
Maximum length between slots Dependent on SDRAM size
Minimum length between slots 8.0 mm (0.32 in)
Note: Under ideal circumstances, a minimum ticket length of 4 mm
(0.16 in) could be used. It requires the sum of the copy length (b) and
the detection slit height (e) to be larger than 7 mm (0.28 in), that batch
printing is used, and that no pull back of the media is performed.
Intermec does not guarantee that such short tickets will work, but it is
up to users to test this in their unique application.
Detection Slit Height (e)
Measurement Value
Maximum 21.3 mm (0.83 in)
Recommended 1.6 mm (0.06 in)
Minimum 1.2 mm (0.05 in)
