Chapter 1 — Using the Printer
22 PM4i Mid-Range Printer User’s Manual
11 Adjust the position of the edge guide on the label slack absorber
according to the width of the media.
12 Close the peel-off assembly and media cover.
13 Adjust the Label Taken Sensor (LTS) so that the media feeds
correctly.
a On your printer’s keypad, press T to enter the Setup menu.
b If you are using Fingerprint, go to PRINT DEFS > LTS > LTS
ADJUST.
If you are using IPL, go to CONFIGURATION > LTS
CALIBRATION and press E.
c Press E to self-calibrate the LTS.
d When you are prompted, remove your test label.
e Press E.
14 Your printer is configured for Peel-Off mode. Press T to exit the
Setup menu.
Edge guide
Label slack absorber
