Chapter 1 — Using the Printer
38 PM4i Mid-Range Printer User’s Manual
IPL Testprint Options
Testprint Description
Config
SW Contains current configuration parameters stored
in the printer’s memory, defined pages, defined
formats, defined graphics, defined fonts, and any
installed printer options.
HW Contains printer memory information; printer
mileage; printhead settings; firmware checksum,
program, and version number.
Network Contains WINS name, MAC address, IP selection, IP
address, netmask, default router, name server, mail
server, primary WINS server, secondary WINS
server, and network statistics.
RFID Test Label Prints an RFID test label that includes the tag type
name.
Test Labels
Pitch Contains an even pattern of small dots that reveals
failing printhead dots and variations of printout
darkness due to uneven printhead pressure or bad
energy regulation to the printhead.
Print Quality Contains bar codes with different characteristics
and useful information about the printer model,
program version, print speed, and media sensitivity
setup.
Format
All > Print Formats Contains a single format that you can use to
evaluate the print quality of a particular format.
This option prints labels for all the formats stored
in the printer’s memory.
Page
All > Print Pages Tests the ability of the printer to receive and print
single or multiple pages of label data that is sent
from the host. This option prints labels for all the
pages stored in the printer’s memory.
