User’s Manual of netMod Network Termination Unit
bit Dec hex Bit mapped register S40=
1 2 2 No result code displayed in answer mode
dec hex Bit mapped register
This register defines the RING answer format. Possible values and
the corresponding RING formats are listed below:
0 RING
1 RING <Called Party Number>
2 RING <Calling Party Number>
4 RING <Bearer Service>
S42=
3 * RING <Called Party Number> ; <Calling Party Number>
S56= 20-
100
Hook flash detect time for analogue Adapter (analogue port); units
10ms. This register’s contents can give a Hook flash detect time of
up 1 second.
Default value is 700 ms (70).
bit dec hex Bit mapped register
0 0 ab1 call-waiting disabled 2
4 * 4 ab1 call-waiting enabled
0 0 ab2 call-waiting disabled
S79=
3
8 * 8 ab2 call-waiting enabled
dec hex Bit mapped register
70 46 V.120 B channel Protocol
72 48 V.110 B channel Protocol
74 4A PPP/ML-PPP B Channel Protocol.
76 4C Voice Transparent B Channel Protocol
78 4E PPP Transparent B Channel Protocol
80 50 Data Transparent B Channel Protocol
82 52 X.75 Transparent B channel Protocol
84 54 X.25 over D channel Protocol
S82=
(***)
86 56 PPP over X.25 over D Channel Protocol (AO/DI)
bit dec hex Bit mapped register
0 * 0 ab1 delayed clear-back enabled. 0
1 1 ab1 delayed clear-back disabled.
0 * 0 ab2 delayed clear-back enabled. 1
2 2 ab2 delayed clear-back disabled.
0* 0 ab1 Reverse Polarity enabled 2
1 1 ab1 Reverse Polarity disabled
0* 0 ab2 Reverse Polarity enabled
S83=
3
1 1 ab2 Reverse Polarity disabled
6
7
