User’s Manual of netMod Network Termination Unit
Bit dec hex Bit mapped register
0* 0 Do not drop any channel if both B channels are used for data bunlde
connection (ML/PPP) in case of an incoming voice call destinated to
port ab1.
0
1 1 Drop one B channel if both B channels are used for data bundle
connection (ML/PPP) in case of an incoming voice call destinated to
port ab1.
0* 0 Do not drop any channel if both B channels are used for data bunlde
connection (ML/PPP) in case of an incoming voice call destinated to
port ab2.
1
2 2 Drop one B channel if both B channels are used for data bundle
connection (ML/PPP) in case of an incoming voice call destinated to
port ab2.
0 * 0 Indicates ON HOOK Caller ID for ab1. 4
16 10 Disable ON HOOK Caller ID indication for ab1.
0 * 0 Indicates ON HOOK Caller ID for ab2. 5
32 20 Disable ON HOOK Caller ID for ab2.
0 0 Indicates OFF HOOK Caller ID for ab1. 6
64 * 40 Disable OFF HOOK Caller ID for ab1.
0 0 Indicates OFF HOOK Caller ID for ab2.
S84=
7
128 * 80 Disable OFF HOOK Caller ID for ab2.
bit dec hex Bit mapped register
0 * 0 Calling Line Identification Restriction disabled on ab1. 0
1 1 Calling Line Identification Restriction enabled on ab1.
0 * 0 Calling Line Identification Restriction disabled on ab2. 1
2 2 Calling Line Identification Restriction enabled on ab2.
0* 0 Connected Line Identification Restriction disabled on ab1. 2
4 4 Connected Line Identification Restriction enabled on ab1.
0 * 0 Connected Line Identification Restriction disabled on ab2.
S85=
3
8 8 Connected Line Identification Restriction enabled on ab2.
0 0 Message Waiting Indication is disabled
1 1 Message Waiting Indication is enabled on ab1
2 2 Message Waiting Indication is enabled on ab2
S86=
3 3 Message Waiting Indication is enabled on both POTS
bit dec hex Bit mapped register
Note: Global calls are those incoming calls that do not contain
Called_Party_Number Information Element in the SETUP message.
0 * 0 Enable ab1 port to receive global calls (see note). 0
1 1 Disable ab1 port to receive global calls (see note).
0 * 0 Enable ab2 port to receive global calls (see note). 1
2 2 Disable ab2 port to receive global calls (see note).
0 * 0 Bundle connection is disabled.
S87=
5-6
96 60 Bundle connection is enabled on outgoing calls.
S89= bit dec hex Bit mapped register
6
8
