18
This Procedure includes the following:
Adjusting/Installing the One-Piece Footboard
Adjusting/Installing the Articulating Footplates
Adjusting/Installing the Swing Under/Non-Swing
Under Footboards
Transferring Swing Under/Non-Swing Under
Footboards
FIGURE 1 - ADJUSTING/INSTALLING THE ONE-PIECE FOOTBOARD
ONE-PIECE FOOTBOARD HEIGHT.
1. Loosen, but do not remove the four (4) socket
screws that secure the half clamps and
footboard support tubes to the wheelchair
frame.
2. Position the footboard support tubes to the de-
sired height.
NOTE: Make sure the footboard support tubes
are the same distance from the bottom of the
wheelchair frame.
3. Securely tighten the four (4) socket screws that
secure the half clamps and footboard support
tubes to the wheelchair frame.
ONE-PIECE FOOTBOARD DEPTH.
NOTE: Observe the angle of the one piece
footboard for reinstallation.
1. Remove the four (4) flat screws and locknuts
that secure the one-piece footboard to the
footboard clamps.
2. Position the one-piece footboard to one (1) of
four (4) depths.
3. Reinstall the four (4) flat screws and locknuts
that secure the one-piece footboard to the
footboard clamps and securely tighten.
Installing
1. Position an open hole half clamp and a threaded
hole half clamp approximately 3-inches from the
bottom of the wheelchair frame. Make sure the
threaded hole half clamp is on the inside of the
wheelchair frame.
Flat Screws
Socket Screws
Locknuts
Threaded Hole
Half Clamps
Open Hole Half
Clamp
Socket Screws
NOTE: Installation shown in standard position only
for clarity. Installation procedure is the same for the
reversed position.
One-Piece
Footboard
Footboard
Clamps
Wheelchair Frame
Footboard
Support Tube
PROCEDURE 1 FRONT RIGGINGS
WARNING
After adjustments and before use, make sure
all attaching hardware is securely tightened.
ADJUSTING/INSTALLING THE ONE-PIECE
FOOTBOARD (FIGURE 1)
WARNING
When determining the angle, depth or height
of the one-piece footboard when the wheelchair
is in the standard position, make sure the back
of the one-piece footboard DOES NOT interfere
with the movement of casters.
NOTE: The one-piece footboard can mount onto
the standard or reversed positions of the wheel-
chair.
Adjusting
ONE-PIECE FOOTBOARD ANGLE.
1. Loosen, but do not remove the four (4) flat
screws and locknuts that secure the one-piece
footboard to the footboard clamps.
2. Adjust the one-piece footboard to the desired
angle for the user.
3. Securely tighten the one-piece footboard to the
footboard clamps with the four (4) flat screws
and locknuts.
F
R
O
N
T
R
I
G
G
I
N
G
S
