Invacare Comet - Height-Long Frame; Large Wheel, Caster Size, Axle

60
S
E
A
T
T
O
F
L
O
O
R
PROCEDURE 8 SEAT-TO-FLOOR
LARGE WHEEL, CASTER SIZE, AXLE PLATE POSITION, AND CASTER FORK FOR
13-3/4 - INCH SEAT-TO-FLOOR HEIGHT- LONG FRAME
NOTE: S18-inch wheel, 3-inch caster 18-inch wheel, 3-inch caster
HEAD
TUBE
NON - MINI TILT
AXLE PLATE
POSITION
HEAD
TUBE
3-INCH FORK
NON - MINI TILT
AXLE PLATE
POSITION
18-inch wheel, 5-inch caster
HEAD
TUBE
18-inch wheel, 5-inch caster
HEAD
TUBE
3-INCH FORK 3-INCH FORK
NON - MINI TILT
AXLE PLATE
POSITION
NON - MINI TILT
AXLE PLATE
POSITION
3-INCH FORK
1-INCH SPACER
NOTE: Seat-to-Floor heights are approximate to
+ 1/2-inch.
STANDARD POSITION
REVERSED POSITION
