SERVICE INSTRUCTIONS
17
Component Check for Measures

• Check that the cable
clamps are firmly
attached to the battery
terminals
• Tighten
Battery fixation belts /
buckles
• Damage • Replace
• Firmly attached • Tighten
Cables / cable looms
• Damage • Replace
• Plug-in connections are
firmly connected
• Firmly press the
connection together (See
"
Checking the cables"
on page
87)
Joystick box / bus cable
• Damage • Replace
• Check that all plug-in
connections are firmly
connected
• Firmly press the plug-in
connection together (See
"
Checking the cables"
on page
87)
• Check that all screws are
tight
• Tighten
• Function • Send in to Invacare to be
repaired, if necessary
replace (See "
Replacing
the ACS Remote
" on
page
90)
Lighting
• Light bulbs defective • Replace
• Casing / glass damaged • Replace
• Position / angle out of
adjustment
• Adjust
Frame
Frame (chassis) / Battery
cradle
• Check fixation, weld
seams and battery cradle
for damage
• Tighten screws, replace
components
Wheels / Tyres
Drive wheels
• Check for tight fit and
axial run out
• Adjust
Steering wheels
• Check for tight fit, check
required motor-to-body
clearance and axial run
out
• Replace wheels or wheel
bearings.
Pneumatic tyres
• Damage • Repair or replace, if
damaged (See
"
Repairing a flat tyre" on
page
97)
Steering mechanism
