Invacare G50 - Page 18

SERVICE INSTRUCTIONS
Invacare
®
- G50
18
Component Check for Measures

Steering connecting rods /
steering connecting rod
heads
• Damage • Replace
• Check that all screws are
tight
• Tighten
Servo
• Function • Check that the plug-in
connection of the servo
cable is firmly connected,
if necessary replace the
cable or servo
• Check the function of the
Servo-Light-Module, if
necessary replace
Drive
Drive unit
• Function
• Check coupling
mechanism
• Replace (See
"
Replacing a motor" on
page
41)
• Tighten screws/nuts,
adjust or replace if
necessary
Coupling mechanism
• Function • Adjust, if necessary
replace damaged part
Parking brake
• Function • Adjust
Legrests
Legrests
• Check welding seams,
locking devices, foot
plates for damage
• Replace
• Check that all screws are
tight
• Tighten
• Check functions • Replace actuator/cable
(See "
Testing an
actuator motor
" on page
101)
• Clean and check the
contacts of the legrest
mounting brackets, if
necessary replace.
Actuator (on electric
legrests)
