Invacare G50 - Page 23

Invacare
®
- G50
SERVICE INSTRUCTIONS
23
Remote status bar
indicator LED blink
code
Servo light
module LED
blink code
Cause Fault remedy
1 -
ACS module defective
• Replace faulty module
See "
Replacing
electronics
components
" on page 77
1
Plug on servo light module
(SLM) defective, or SLM
defective
• Replace faulty module
See "
Replacing
electronics
components
" on page 77
2
Error at servo motor
• Replace servo motor.
2 -
Faulty accessory (e.g. short
circuit on adjustment motor)
• Check accessory
connections, check
accessories See "
Testing
an actuator motor
" on
page
101
3
Potentiometer on servo motor
(steering) defective
• Replace potentiometer.
4
Lighting system defective
(error in SLM or in cabling)
• Check cable, replace
SLM. See "
Replacing
electronics
components
" on page 77
5
Steering disengaged
• Re-engage the steering:
Switch the electronics
system off and on again.
3 -
Motor connection
loose/defective or motor
defective (M1)
• Check the connecting
plug See "
Checking the
cables
" on page 87
• Replace motor See
"
Replacing a motor" on
page
41
4 -
Motor connection
loose/defective or motor
defective (M2)
• Check the connecting
plug See "
Checking the
cables
" on page 87
• Replace motor See
"
Replacing a motor" on
page
41
5 -
Magnetic brake defective or
drive disengaged
• Engage motor. Switch the
electronics system off and
on again.
• Check the connecting
plug
• Replace motor See
"
Replacing a motor" on
page
41
