Invacare G50 - Page 44

SERVICE INSTRUCTIONS
Invacare
®
- G50
44
• Secure the drive unit with wooden blocks
against falling down.
• The brake is held by four screws (1).
• Loosen and remove the screws, using the
Allen key with ball end 3 mm.
• Pull the brakes (1) on both side off in an
outward direction.
