SERVICE INSTRUCTIONS
Invacare
®
- G50
50
• The outer bushing (1) is not secured with
anaerobic metal adhesive, only inserted
loosely.
• Loosen and remove the bushing (1), using the
water pump pliers.
• The inner bushing (1) is secured with metal
adhesive and cannot be removed from the
trailing arm. For this reason, the complete
trailing arm must be replaced along with the
bushing.
• Counter the lower fixation bolt of the shock
absorber (1), using an Allen key 6 mm, to
prevent it from turning, and loosen and
remove the nut (2), using the open-end
spanner 13 mm.
• Pull the bolt out.
