General Information and Ratings
2
2.1.3. IP55 Enclosed Units
200 – 240 Volt, 3 Phase Input
Frame
kW
HP
A
Model Code
4
7.5
10
30
ODV-3-420300-3F1N-TN
4
11
15
46
ODV-3-420460-3F1N-TN
5
15
20
61
ODV-3-520610-3F1N-TN
5
19
25
72
ODV-3-520720-3F1N-TN
6
22
30
90
ODV-3-620900-3F1N-TN
6
30
40
110
ODV-3-621100-3F1N-TN
6
37
50
150
ODV-3-621500-3F1N-TN
6
45
60
180
ODV-3-621800-3F1N-TN
7
55
75
202
ODV-3-722020-3F1N-TN
7
75
100
248
ODV-3-722480-3F1N-TN
380 – 480 Volt, 3 Phase Input
Frame
kW
HP
A
Model Code
4
15
20
30
ODV-3-440300-3F1N-TN
4
19
25
39
ODV-3-440390-3F1N-TN
4
22
30
46
ODV-3-440460-3F1N-TN
5
30
40
61
ODV-3-540610-3F1N-TN
5
37
50
72
ODV-3-540720-3F1N-TN
5
45
60
90
ODV-3-540900-3F1N-TN
6
55
75
110
ODV-3-641100-3F1N-TN
6
75
100
150
ODV-3-641500-3F1N-TN
6
90
150
180
ODV-3-641800-3F1N-TN
7
110
175
202
ODV-3-742020-3F1N-TN
7
132
200
240
ODV-3-742400-3F1N-TN
7
160
250
302
ODV-3-743020-3F1N-TN
480 – 525 Volt, 3 Phase Input
Frame
kW
HP
A
Model Code
7
132
175
185
ODV-3-751850-301N-TN
7
150
200
205
ODV-3-752050-301N-TN
7
185
250
255
ODV-3-752550-301N-TN
7
200
270
275
ODV-3-752750-301N-TN
500 – 600 Volt, 3 Phase Input
Frame
kW
HP
A
Model Code
4
15
20
22
ODV-3-460220-301N-TN
4
19
25
28
ODV-3-460280-301N-TN
4
22
30
34
ODV-3-460340-301N-TN
4
30
40
43
ODV-3-460430-301N-TN
5
37
50
54
ODV-3-560540-301N-TN
5
45
60
65
ODV-3-560650-301N-TN
5
55
75
78
ODV-3-560780-301N-TN
6
75
100
105
ODV-3-661050-301N-TN
6
90
125
130
ODV-3-661300-301N-TN
6
110
150
150
ODV-3-661500-301N-TN
2.2. Identifying the Drive by Model Number
Each drive can be identified by its model number, shown below. The model number is on the shipping label and the drive nameplate. The
model number includes the drive and factory fitted options.
ODV
-
3
-
4
4
0460
-
3
F
1
N
-
T
N
Product Range
PCB Coating
ODV : Eco Series
N : Standard PCB Coating
Generation
Display
Frame Size
S : LED IP20 Only
Voltage Code
T : OLED IP55 & IP66
2 : 200 – 240
Enclosure
4 : 380 – 480
2 : IP20
5 : 480 – 525
N : IP55
6 : 500 – 600
X : IP66 Non Switched
Output Current
D : IP66 With Disconnect
Shown with 1 decimal place
Brake Transistor
Supply Phase
1 : No Brake Transistor
1 : 1 Phase Input
EMC Filter
3 : 3 Phase Input
0 : No EMC Filter
F : With EMC Filter
