Invertek Drives Optidrive E3 ODE-3 Series - Network (IP Address and Network Settings); DiagLink (Ethernet Configuration Message); Network (Ethernet Network Statistics)

Version 1.02 | Fieldbus Guide | 19www.invertekdrives.com
7
Internal Webserver
7
Internal Webserver
7.3.3. Network (IP Address and Network Settings)
Information about network adapter configuration is displayed.
7.3.4. DiagLink (Ethernet Configuration Message)
Information about the serial communication settings to the drive are displayed.
7.3.5. Network (Ethernet Network Statistics)
Statistic information about the ethernet connections is displayed.
7.3.4. DiagLink (Ethernet Configuration Message)
Information about the serial communication settings to the drive are displayed.
7.3.5. Network (Ethernet Network Statistics)
Statistic information about the ethernet connections is displayed.
