DA180 series basic AC servo drive Installation instructions
-15-
2.1 Drive dimensions
2.1.1 Dimension drawing for frame size A/B
2
N
C
W
V
U
C
3
N
1
N
C
L1
B3
B2
L2
CH A RG E
4
N
C
2.1.2 Models and dimensions
Frame size
Model
Outline dimensions
Mount
dimensions
Mount hole
(mm)
H
(mm)
W
(mm)
D
(mm)
A
(mm)
B
(mm)
A
DA180-S1R3SG0
160
42
141
32
150
M4(Φ5)
DA180-S1R8SG0
DA180-S2R8SG0
B
DA180-S4R5SG0
160
50
141
40
150
M4(Φ5)
DA180-S5R0SG0
