INVT DA180-S4R5SG0

DA180 series basic AC servo drive Control modes
-49-
4.4.5 Pulse input signals and functions
Sign
Pin
Signal
Function
OCP
38
Position command
pulse input 1
 In position control mode, the terminals function as
position command input terminals.
 In other control modes, the terminals are invalid.
 The maximum input pulse frequency is 4 MHz in
differential mode and 200 kHz in open collector
mode.
PULS+
23
PULS-
24
OCS
31
Position command
pulse input 2
SIGN+
32
SIGN-
33
4.4.6 Analog input signals and functions
Sign
Pin
Signal
Default
Input
Function
AD1
20
Analog input 1
0x03
Speed
command
 AD1 and AD2 are accurate to 12 bits.
 For external analog input terminals,
the input impedance is 13kΩ, and the
input voltage ranges from -10V to
+10V. If the voltage is out of the range
of -11V–+11V, the drive may be
damaged.
 The range, offset, and function
definition are configurable.
AD2
7
Analog input 2
0x04
Torque
command
GND
6
Signal ground
-
-
4.4.7 Encoder output signals and functions
Sign
Pin
Signal
Function
OA+
44
Phase-A output
 The output of encoder signal that is frequency
divided is compliant with TIA/EIA-422-B.
 The output phase-A pulse and phase-B pulse are
still orthogonal. In forward rotation, phase A leads
phase B by 90°. In reverse rotation, phase B leads
phase A by 90°.
 The frequency can be divided or multiplied by any
integer or fraction.
OA-
43
OB+
41
Phase-B output
OB-
42
OZ+
28
Phase-Z output
OZ-
27
