INVT DA180-S4R5SG0

DA180 series basic AC servo drive Function codes
-208-
Modbus address
3656, 3657
CANopen address
0x2D1C, 0x00
PtP2.30
Data size
32bit
Data format
HEX
Modbus address
3660, 3661
CANopen address
0x2D1E, 0x00
PtP2.32
Data size
32bit
Data format
HEX
Modbus address
3664, 3665
CANopen address
0x2D20, 0x00
PtP2.34
Data size
32bit
Data format
HEX
Modbus address
3668, 3669
CANopen address
0x2D22, 0x00
PtP2.36
Data size
32bit
Data format
HEX
Modbus address
3672, 3673
CANopen address
0x2D24, 0x00
PtP2.38
Data size
32bit
Data format
HEX
Modbus address
3676, 3677
CANopen address
0x2D26, 0x00
PtP2.40
Data size
32bit
Data format
HEX
Modbus address
3680, 3681
CANopen address
0x2D28, 0x00
PtP2.42
Data size
32bit
Data format
HEX
Modbus address
3684, 3685
CANopen address
0x2D2A, 0x00
PtP2.44
Data size
32bit
Data format
HEX
Modbus address
3688, 3689
CANopen address
0x2D2C, 0x00
PtP2.46
Data size
32bit
Data format
HEX
Modbus address
3692, 3693
CANopen address
0x2D2E, 0x00
PtP2.48
Data size
32bit
Data format
HEX
Modbus address
3696, 3697
CANopen address
0x2D30, 0x00
PtP2.50
Data size
32bit
Data format
HEX
Modbus address
3700, 3701
CANopen address
0x2D32, 0x00
PtP2.52
Data size
32bit
Data format
HEX
Modbus address
3704, 3705
CANopen address
0x2D34, 0x00
PtP2.54
Data size
32bit
Data format
HEX
Modbus address
3708, 3709
CANopen address
0x2D36, 0x00
PtP2.01
Position of
segment 100
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP2.03
Position of
segment 101
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP2.05
Position of
segment 102
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
PtP2.07
Position of
segment 103
Setting range
Default
Unit
Applicable
mode
-(2
31
-1)–(2
31
-1)
0
reference unit
P
