Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-104-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
drop
P12 Group Motor 2
P12.01
Rated power
of
asynchronous
motor 2
0.1~3000.0kW
Set the parameter of the
controlled asynchronous
motor.
In order to ensure the control
performance, set the
P12.01~P12.05 according to
the name plate of
asynchronous motor.
Goodrive300-19 series
inverters provide the function of
parameter autotuning. Correct
parameter autotuning comes
from the correct setting of the
motor name plate.
In order to ensure the control
performance, please configure
the motor according to the
standard principles, if the gap
between the motor and the
standard one is huge, the
control performance of the
inverter will decrease.
Note: Resetting P12.01 can
initialize P12.02~P12.05
Depend
on
model
◎
P12.02
Rated
frequency of
asynchronous
motor 2
0.01Hz~P00.03 (the
Max. frequency)
50.00Hz
◎
P12.03
Rated speed
of
asynchronous
motor 2
1~36000rpm
Depend
on
model
◎
P12.04
Rated voltage
of
asynchronous
motor 2
0~1200V
Depend
on
model
◎
P12.05
Rated current
of
asynchronous
motor 2
0.8~6000.0A
Depend
on
model
◎
P12.06
Stator resistor
of
asynchronous
motor 2
0.001~65.535Ω
After completing the motor
parameter autotuning, the set
value of P12.06~P12.10 will
will update automatically. As
the basic parameters of high
performance vector control, the
parameters have a direct
Depend
on
model
○
P12.07
Rotor resistor
of
asynchronous
0.001~65.535Ω
Depend
on
model
○
