Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-107-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
P13.15
Braking
retention
time when
stopping
set by P01.12 (refer to the instruction of
P01.09~P01.12) .
Setting range of P13.13: 0.0~150.0% (the inverter)
Setting range of P13.14: 0.0~50.0s
Setting range of P13.15: 0.0~50.0s
0.00s
○
P14 Group Serial communication
P14.00
Local
communicatio
n address
The setting range: 1~247
When the master is writing the frame, the
communication address of the slave is set to 0; the
address is the communication address. All slaves on
the Modbus fieldbus can receive the frame, but the
salve does not answer.
The communication of the drive is unique in the
communication net. This is the fundamental for the
point to point communication between the upper
computer and the drive.
Note: The address of the slave cannot be set to 0.
1
○
P14.01
Communicatio
n baud ratio
Set the digital transmission speed between the upper
computer and the inverter.
0: 1200BPS
1: 2400BPS
2: 4800BPS
3: 9600BPS
4: 19200BPS
5: 38400BPS
6: 57600BPS
7: 115200BPS
Note: The baud rate between the upper computer
and the inverter must be the same. Otherwise, the
communication is not applied. The bigger the
baud rate, the quicker the communication speed.
4
○
P14.02
Digital bit
checkout
The data format between the upper computer and the
inverter must be the same. Otherwise, the
1
○
