Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-124-
forward
rotation in
torque control
1: AI1
2: AI2
3: AI3
4: Pulse frequency HDI setting upper-limit frequency
5: Multi-step setting upper-limit frequency
6: Modbus communication setting upper-limit frequency
7~9: Reserved
Note: Setting modes 1~6, 100% corresponds to the
maximum frequency.
P03.15
Upper
frequency of
reverse
rotation in
torque control
0: Keypad (set by P03.17)
1~9: The same as P03.14
0
P03.16
Keypad setting
for upper
frequency of
forward
rotation
Setting range: 0.00 Hz~P00.03 (the Max. output
frequency)
50.00Hz
P03.17
Keypad setting
for upper
frequency of
reverse
rotation
50.00Hz
P03.18
Upper
electromotion
torque source
0: Keypad setting upper-limit frequency (set by P03.20)
1: AI1
2: AI2
3: AI3
4: HDI
5: Modbus communication
6~8: Reserved
Note: Setting modes 1~5, 100% corresponds to three
0
