INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-123-
P03.05
High switching
frequency
P03.02~P00.03 (the Max. output frequency)
10.00Hz
P03.06
Speed loop
output filter
0~8 (corresponding to 0~2
8
/10ms)
0
P03.07
Compensation
coefficient of
electromotion
slip
50%~200%
100%
P03.08
Compensation
coefficient of
braking slip
50%~200%
100%
P03.09
Current loop
percentage
coefficient P
0~65535
1000
P03.10
Current loop
integral
coefficient I
0~65535
1000
P03.11
Torque
setting
method
0: Torque control is invalid
1: Keypad setting torque (P03.11)
2: Analog AI1 setting torque
3: Analog AI2 setting torque
4: Analog AI3 setting torque
5: Pulse frequency HDI setting torque
6: Multi-step torque setting
7: Modbus communication setting torque
8~10: Reserved
Note: Setting modes 2~7, 100% corresponds to three
times of the rated current of the motor.
0
P03.12
Keypad
setting torque
-300.0%~300.0% (rated current of the motor)
50.0%
P03.13
Torque
reference
filter time
0.000~10.000s
0.010s
P03.14
Upper
frequency of
0: Keypad (P03.16 sets P03.14, P03.17 sets P03.15)
0
