INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-129-
When the user selects the user-defined V/F curve function in Goodrive300-19 series inverters, they
can set the reference channel of voltage and frequency and the corresponding ACC/DEC time, or the
two can combinate to form a real-time curve.
Note: The application of V/F curve separation can be used in many cases with various kinds of
power supply of the inverter. But the users should set and adjust the parameters with caution.
Incorrect parameters may cause damage to the inverter.
Function
code
Name
Detailed instruction of parameters
Default
value
P00.00
Speed
control mode
1: Sensorless vector control mode 1
2: SVPWM control mode
1
P00.03
Max. output
frequency
P00.04~400.00Hz
50.00Hz
P00.04
Upper limit of
running
frequency
P00.05~P00.03
50.00Hz
P00.05
Lower limit of
running
frequency
0.00Hz~P00.04
0.00Hz
P00.11
ACC time 1
0.0~3600.0s
Depend
on model
P00.12
DEC time 1
0.0~3600.0s
Depend
on model
P02.02
Rated
frequency of
asynchronous
motor 1
0.01Hz~P00.03
(the Max. frequency)
50.00Hz
P02.04
Rated voltage
of
asynchronous
motor 1
0~1200V
Depend
on model
P04.00
Motor 1 V/F
curve setting
0: Straight line V/F curve
1: Multi-dots V/F curve
2: 1.3th power low torque V/F curve
3: 1.7th power low torque V/F curve
4: 2.0th power low torque V/F curve
0
