Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-136-
reverse
rotation in
torque control
2: AI2 (the same as above)
3: AI3 (the same as above)
4: Pulse frequency HDI setting upper-limit frequency (the
same as above)
5: Multi-step setting upper-limit frequency (the same as
above)
6: Modbus communication setting upper-limit frequency
(the same as above)
7~9: Reserved
P03.16
Keypad
setting for
upper
frequency of
forward
rotation
0.00 Hz~P00.03 (the Max. output frequency)
50.00Hz
P03.17
Keypad
setting for
upper
frequency of
reverse
rotation
0.00 Hz~P00.03 (the Max. output frequency)
50.00Hz
P03.18
Upper
electromotion
torque
source
0: Keypad setting upper-limit frequency (P03.20)
1: AI1 (100% corresponds to three times of the rated
current of the motor)
2: AI2 (the same as above)
3: AI3 (the same as above)
4: HDI (the same as above)
5: Modbus communication (the same as above)
6~8: Reserved
0
P03.19
Upper
braking
torque
0: Keypad setting upper-limit frequency (P03.21)
1: AI1 (100% corresponds to three times of the rated
current of the motor)
0
