INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-158-
16~21: Reserved
22:Torque current (relative to 3 times of rated current of
the motor)
23: Pre-magnetizing current (relative to the rated current of
the motor)
24~30: Reserved
P06.17
Lower output
limit of AO1
-100.0%~P06.19
0.0%
P06.18
Corresponding
AO1 output of
lower limit
0.00V~10.00V
0.00V
P06.19
Upper output
limit of AO1
P06.17~100.0%
100.0%
P06.20
Corresponding
AO1 output of
upper limit
0.00V~10.00V
10.00V
P06.21
AO1 output
filter time
0.000s~10.000s
0.000s
P06.22
Lower output
limit of AO2
0.0%~P06.24
0.0%
P06.23
Corresponding
AO2 output of
lower limit
0.00V~10.00V
0.00V
P06.24
Upper output
limit of AO2
P06.22~100.0%
100.0%
P06.25
Corresponding
AO2 output of
upper limit
0.00V~10.00V
10.00V
P06.26
AO2 output
filter time
0.000s~10.000s
0.000s
P06.27
Lower output
limit of HDO
-100.0%~P06.29
0.00%
P06.28
Corresponding
HDO output of
lower limit
0.00~50.00kHz
0.00kHz
