Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-157-
Set value
Function
Instruction
14
Setting value 1 of Modbus
communication
-1000~1000, 1000 corresponds to 100.0%
15
Setting value 2 of Modbus
communication
-1000~1000, 1000 corresponds to 100.0%
16~21
Reserved
22
Torque current (relative to the
rated current of the motor)
0~2 times of the rated current of the motor
23
Exciting current (relative to
the rated current of the
motor)
0~2 times of the rated current of the motor
24~30
Reserved
Relative parameters list:
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0: Open collector high-speed pulse output
1: Open collector output
0
P06.14
AO1 output
0: Running frequency
1: Set frequency
2: Ramp reference frequency
3: Running rotation speed
4: Output current (relative to 2 times of rated current of the
inverter)
5: Output current (relative to 2 times of rated current of the
motor)
6: Output voltage
7: Output power
8: Set torque value
9: Output torque
10: AI1 input value
11: AI2 input value
12: AI3 input value
13: High-speed pulse HDI input value
14: Modbus communication set value 1
15: Modbus communication set value 2
0
P06.15
AO2 output
1
P06.16
HDO
high-speed
pulse output
0
