INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-160-
9
External fault input
37
Shift the command to
the terminal
10
Frequency setting
increasing (UP)
38
Shift the command to
the communication
11
Frequency setting
decreasing (DOWN)
39
Pre-magnetized
command
12
Frequency setting
clear
40~56
Reserved
13
Shifting between A
frequency and B
frequency
57
Inverter enabling
14
Shifting between the
combination setting
and A frequency
58
Contactor feedback
signal
15
Shifting between the
combination setting
and B frequency
59
Brake feedback
signal
16
Multi-step speed
terminal 1
60
Joystick zero position
signal
17
Multi-step speed
terminal 2
61
Hierarchical
reference terminal 1
18
Multi-step speed
terminal 3
62
Hierarchical
reference terminal 2
19
Multi-step speed
terminal 4
63
Hierarchical
reference terminal 3
20
Multi-step speed
pause
64
Hierarchical
reference terminal 4
21
ACC/DEC time
selection 1
65
Hierarchical
reference terminal 5
22
ACC/DEC time
selection 2
This parameter is used to set the function corresponding to the digital multi-function input terminals.
Note: Two different multi-function terminals can not be set as one function.
Set
value
Function
Instruction
0
No function
The inverter does not work even when there is input
signal. It is necessary to set the terminal which cannot
be used to non-function to avoid misacting.
1
Forward running (FWD)
The forward or reverse rotation of the inverter can be
