Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-162-
Set
value
Function
Instruction
given frequency channel.
13
Shifting between A frequency
and B frequency
This function can realize the shifting between the
frequency setting channels.
The 13
th
function can realize the shifting between A
frequency reference channel and B frequency
reference channel.
The 14
th
function can realize the shifting between A
frequency given channel and the combination setting
channel set by P00.09
The 15
th
function can realize the shifting between B
frequency given channel and the combination setting
channel set by P00.09
14
Shifting between the
combination setting and A
frequency
15
Shifting between the
combination setting and B
frequency
16
Multi-step speed terminal 1
The 16 stage speeds can be set by the combination of
digital state of four terminals.
Note: Multi-step speed 1 is the low bit, multi-step
speed 4 is the high bit.
Multi-step
speed 4
Multi-step
speed 3
Multi-step
speed 2
Multi-step
speed 1
BIT3
BIT2
BIT1
BIT0
17
Multi-step speed terminal 2
18
Multi-step speed terminal 3
19
Multi-step speed terminal 4
20
Multi-step speed pause
Shield the multi-step speed selection terminal function
to keep the setting value at the current state.
21
ACC/DEC time selection 1
Select 4 ACC/DEC time by the combination of the 2
terminals.
Terminal
1
Terminal
2
ACC/DEC time
selection
Corresponding
parameter
OFF
OFF
ACC/DEC time 1
P00.11/P00.12
ON
OFF
ACC/DEC time 2
P08.00/P08.01
OFF
ON
ACC/DEC time 3
P08.02/P08.03
ON
ON
ACC/DEC time 4
P08.04/P08.05
22
ACC/DEC time selection 2
23~28
Reserved
29
Torque control disabling
The inverter shifts from torque control mode to speed
control mode.
30
ACC/DEC disabling
Ensure the inverter will not be affected by the external
