INVT Goodrive300-19 Series User Manual

Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-169-
4
Jogging operation
23
Modbus
communication
virtual terminals
output
5
Inverter fault
24~32
Reserved
6
FDT1
33
Contactor control
7
FDT2
34
Brake control
8
Frequency arrival
35
Ready for switching
off
9
Zero speed running
36
Ready for switching
on
10
Upper limit frequency
arrival
37
Motor 2 in operation
11
Lower limit frequency
arrival
12
Ready for operation
13
Pre-magnetizing
The below table is the option of the four function parameters and selecting the repeated output
terminal function is allowed.
Set value
Function
Instruction
0
Invalid
The output terminal has no function.
1
In operation
Output ON signal when the inverter is running and
there is frequency output.
2
Forward rotation operation
Output ON signal when the inverter is running
forward and there is frequency output.
3
Reverse rotation operation
Output ON signal when the inverter is running
reverse and there is frequency output.
4
Jogging operation
Output ON signal when the inverter is jogging and
there is frequency output.
5
Inverter fault
Output ON signal when the inverter is in fault
6
FDT1
Please refer to P08.32 and P08.33 for detailed
information.
7
FDT2
Please refer to P08.34 and P08.35 for detailed
information.
8
Frequency arrival
Please refer to P08.36 for detailed information.
9
Zero speed running
Output ON signal when the output frequency and
