Goodrive300-19 series open loop vector inverter special for hosit Basic operation instruction
-186-
Function
code
Name
Function
selection
Function instruction
P00.01
Running command channel
1
Terminal running command
channel (LED flickering)
P00.06
A frequency command
13
Hierarchical multi-step speed
reference
P05.01
S1 terminal function selection
1
Forward rotation operation (FWD)
P05.02
S2 terminal function selection
2
Reverse rotation operation (REV)
P05.03
S3 terminal function selection
7
Fault reset (RET)
P05.04
S4 terminal function selection
61
Hierarchical reference terminal 1
P05.05
S5 terminal function selection
62
Hierarchical reference terminal 2
P05.06
S6 terminal function selection
63
Hierarchical reference terminal 3
P05.07
S7 terminal function selection
60
Joystick zero position signal
P06.03
Relay RO1 output
5
Fault output
P06.04
Relay RO2 output
34
Brake control output
P06.14
AO1 output
0
Running frequency
P06.15
AO2 output
5
Current output
P19.01
Brake and contactor control
selection
0x01
Brake is controlled by inverter
7.16.5 Hierarchical remote control mode
The wiring diagram of hierarchical remote control mode is as follows:
GD300-19 inverter
FWD running
S1
Frequency reference Hierarchical multi-step speed reference
REV running
S2
Fault reset
S3
RO1
Brake output
RO2
Fault output
AO1
Running frequency
AO2
Current output
Hierarchical reference
terminal 1
S4
S5
S6
Hierarchical reference
terminal 2
Hierarchical reference
terminal 3
The mode is used in the case where the digital input is connected to the remote controller or PLC of
hierarchical reference contacts. Set P19.00 to “4: Hierarchical remote control mode”.
The forward and reverse direction signals of the hoist are given by S1 and S2, and the speed is given
