Goodrive300-19 series open loop vector inverter special for hosit Communication protocol
-220-
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
torque (0~3000, 1000 corresponds to the
100.0% of the rated current of the motor)
2008H
The upper limit torque of braking torque
(0~3000, 1000 corresponds to the 100.0%
of the rated current of the motor)
W/R
2009H
Special control command word
Bit0~1: =00:motor 1 =01:motor 2
=10:reserved =11:reserved
Bit2: =1:torque control =0:speed control
Bit3: =1:power consumption clear
=0:no power consumption clear
Bit4: =1:pre-exciting enabling
=0: pre-exciting disabling
Bit5: =1:DC braking enabling
=0: DC braking disabling
W/R
200AH
Virtual input terminal command , range:
0x000~0x1FF
W/R
200BH
Virtual output terminal command , range:
0x00~0x0F
W/R
200CH
Voltage setting value (special for V/F
separation)
(0~1000, 1000 corresponds to the 100.0%)
W/R
200DH
AO output setting 1
(-1000~1000, 1000 corresponds to 100.0%)
W/R
200EH
AO output setting 2
(-1000~1000, 1000 corresponds to 100.0%)
W/R
SW 1 of the inverter
2100H
0001H:forward running
R
0002H:forward running
0003H:stop
0004H:fault
0005H:POFF state
0006H:pre-exciting state
SW 2 of the inverter
2101H
Bit0: =0:ready for operation =1:not ready
for operation
Bi1~2: =00:motor 1 =01:motor 2
R
