INVT Goodrive300-19 Series - Page 222

Goodrive300-19 series open loop vector inverter special for hosit Communication protocol
-221-
Function
instruction
Address
definition
Data meaning instruction
R/W
characteristics
=10:reserved =11:reserved
Bit3: =0:asynchronous motor =1:reserved
Bit4: =0:pre-alarm without overload
=1:overload pre-alarm
Bit5~Bit6: =00: keypad control =01: terminal
control
=10: communication control
Fault code of the
inverter
2102H
See the fault type instruction
R
Identifying code of
the inverter
2103H
Goodrive300-19-----0x011a
R
Running frequency
3000H
0~Fmax (unit: 0.01Hz)
Compatible with
communication
addresses of
CHF100A and
CHV100
R
Set frequency
3001H
0~Fmax (unit: 0.01Hz)
R
Bus voltage
3002H
0.0~2000.0V (unit: 0.1V)
R
Output voltage
3003H
0~1200V (unit: 1V)
R
Output current
3004H
0.0~3000.0A (unit: 0.1A)
R
Rotation speed
3005H
0~65535 (unit: 1RPM)
R
Output power
3006H
-300.0~300.0% (unit:
0.1%)
R
Output torque
3007H
-250.0~250.0% (unit:
0.1%)
R
Close loop setting
3008H
-100.0~100.0% (unit:
0.1%)
R
Close loop feedback
3009H
-100.0~100.0% (unit:
0.1%)
R
Input IO state
300AH
000~01FF
R
Output IO state
300BH
000~01FF
R
Analog input 1
300CH
0.00~10.00V (unit: 0.01V)
R
Analog input 2
300DH
0.00~10.00V (unit: 0.01V)
R
Analog input 3
300EH
-10.00~10.00V (unit:
0.01V)
R
Analog input 4
300FH
R
Read input of
high-speed pulse 1
3010H
0.00~50.00kHz (unit:
0.01Hz)
R
Read input of
3011H
R
