Goodrive300-19 series open loop vector inverter special for hosit Communication protocol
-222-
Read the current
stage of multi-step
speed
-300.0~300.0% (unit:
0.1%)
Identifying code of
the inverter
R/W characteristics means the function is with read or write characteristic. For example,
“communication control command” is writing characteristic and control the inverter with writing
command (06H). R characteristic can only read other than write and W characteristic can only write
other than read.
Note: when operating the inverter with the table above, it is necessary to enable some parameters.
For example, the operation of running and stopping, it is necessary to set P00.01 to communication
running command channel.
The encoding rules for device codes (corresponds to identifying code 2103H of the inverter)
GD100 simple vector inverter
GD300-19 open loop vector inverter special for hoist
10.4.5 Fieldbus ratio values
The communication data is expressed by hex in actual application and there is no radix point in hex.
For example, 50.12Hz cannot be expressed by hex, so 50.12 can be magnified by 100 times into
