Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-85-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
BIT3: output terminals state
BIT4~BIT5: reserved
BIT6: torque set value (% on)
BIT7: AI1 (V on)
BIT8: AI2 (V on)
BIT9: AI3 (V on)
BIT10: HDI frequency
BIT11: the current stage in multi-step speed
BIT12~BIT15: reserved
P07.08
Frequency
coefficient
0.01~10.00
Displayed frequency=running frequency* P07.08
1.00
○
P07.09
Rotation
speed
coefficient
0.1~999.9%
Mechanical rotation speed=120*displayed running
frequency×P07.09/motor pole pairs
100.0%
○
P07.10
Linear
speed
coefficient
0.1~999.9%
Linear speed=mechanical rotation speed×P07.10
1.0%
○
P07.11
Rectifier
bridge
module
temperature
-20.0~120.0°C
●
P07.12
Converter
module
temperature
-20.0~120.0°C
●
P07.13
Software
version
1.00~655.35
●
P07.14
Local
accumulative
running time
0~65535h
●
P07.15
High bit of
power
consumption
Display the power used by the inverter.
Power consumption of the inverter
=P07.15*1000+P07.16
Setting range of P07.15: 0~65535 kWh(*1000)
●
P07.16
Low bit of
●
