Goodrive300-19 series open loop vector inverter special for hosit Function parameters
-84-
Function
code
Name
Detailed instruction of parameters
Default
value
Modify
3: Valid for all control modes
P07.05
Parameters
state 1
0x0000~0xFFFF
BIT0: running frequency (Hz on)
BIT1: set frequency (Hz flickering)
BIT2: bus voltage (Hz on)
BIT3: output voltage (V on)
BIT4: output current (A on)
BIT5: running rotation speed (rpm on)
BIT6: output power (% on)
BIT7: output torque (% on)
BIT8~BIT9: reserved
BIT10: input terminals state
BIT11: output terminals state
BIT12: torque set value (% on)
BIT13~BIT14: reserved
BIT15: the current stage in multi-step speed
0x03FF
○
P07.06
Parameters
state 2
0x0000~0xFFFF
BIT0: AI1 (V on)
BIT1: AI2 (V on)
BIT2: AI3 (V on)
BIT3: HDI frequency
BIT4: motor overload percentage (% on)
BIT5: inverter overload percentage (% on)
BIT6: ramp frequency reference value (Hz on)
BIT7: linear speed
BIT8: AC inlet current (A on)
BIT9~15: reserved
0x0000
○
P07.07
Parameters
for stopping
state
0x0000~0xFFFF
BIT0: set frequency (Hz on, frequency flickering
slowly)
BIT1: bus voltage (V on)
BIT2: input terminals state
0x00FF
○
