INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
158
Relative parameters list:
Function
code
Name
Detailed instruction of parameters
Default
value
P00.01
Run command channel
0: Keypad running command (LED off)
1: Terminal running command channel
(LED flickering)
2: Communication running command
channel (LED on)
0
P00.11
ACC time 1
0.0–3600.0 s
Depend on
model
P00.12
DEC time 1
0.0–3600.0 s
Depend on
model
P01.00
Start mode
0: Start-up directly
1: Start-up after DC brake
2: Start-up after rotation speed tracking
0
P01.01
Starting frequency of direct start
0.00–50.00 Hz
0.00 Hz
P01.02
Retention time of the starting
frequency
0.0–50.00 s
0.00s
P01.03
The brake current before starting
0.0–100.0%
0.0%
P01.04
The brake time before starting
0.0–30.0 s
0.0s
P01.05
ACC/DEC selection
0: Linear type
1: S curve
0
P01.06
ACC time of the starting step of S
curve
0.0–50.0s
0.1s
P01.07
DEC time of the ending step of S
curve
0.0–50.0s
0.1s
P01.08
Stop mode
0: Decelerate to stop
1: Coast to stop
0
P01.09
Starting frequency of DC brake
0.00 Hz–P00.03 (max. output
frequency)
0.00 Hz
P01.10
Waiting time of DC brake
0.00–30.00 s
0.00s
P01.11
DC brake current
0.0–100.0%
0.0%
P01.12
DC brake time
0.0–50.0 s
0.0 s
P01.13
Dead time of FWD/REV rotation
0.0–3600.0 s
0.0 s
P01.14
Shifting between FWD/REV
rotation
0: Switch after zero frequency
1: Switch after the starting frequency
0
P01.15
Stopping speed
0.00–100.00 Hz
0.20 Hz
P01.16
Detection of stopping speed
0: Speed setting (the only detection
method in SVPWM mode)
1: Speed detecting value
0
