INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
167
Output instructions:
Set
value
Function
Instructions
0
Running frequency
0–max. output frequency
1
Set frequency
0–max. output frequency
2
Ramp reference frequency
0–max. output frequency
3
Running speed
0–2 times of the rated synchronous rotation
speed of the motor
4
Output current (relative to the VFD)
0–2 times of rated current of the VFD
5
Output current (relative to the motor)
0–2 times of rated current of the VFD
6
Output voltage
0–1.5 times of the rated VFD voltage
7
Output power
0–2 times of the rated power
8
Setting torque value
0–2 times of rated current of the motor
9
Output torque
0–2 times of rated current of the motor
10
AI1
0–10 V/0–20 mA
11
AI2
0–10 V/0–20 mA
12
AI3
-10 V–10 V
13
HDI
0.00–50.00 kHz
14
Setting value 1 of Modbus communication
-1000–1000, 1000 corresponds to 100.0%
15
Setting value 2 of Modbus communication
-1000–1000, 1000 corresponds to 100.0%
16
Setting value 1 of PROFIBUS/CANopen
communication
-1000–1000, 1000 corresponds to 100.0%
17
Setting value 2 of PROFIBUS/CANopen
communication
-1000–1000, 100 corresponds to 100.0%
18
Setting value 1 of Ethernet communication
-1000–1000, 1000 corresponds to 100.0%
19
Setting value 2 of Ethernet communication
-1000–1000, 100 corresponds to 100.0%
20–21
Reserved
22
Torque current (bipolar, 100% corresponds
to 10 V)
0–2 times of the rated current of the motor
23
Exciting current (100% corresponds to 10 V)
0–1 time of the rated current of the motor
24
Setting frequency (bipolar)
0–max. output frequency
25
Ramp reference frequency (bipolar)
0–max. output frequency
26
Operation speed (bipolar)
0–max. output frequency
27–30
Reserved
Relative parameters list:
Function
code
Name
Detailed instruction of parameters
Default
value
P06.00
HDO output
0: Open collector pole high speed pulse output
1: Open collector pole output.
0
