INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Basic operation instruction
175
Function
code
Name
Detailed instruction of parameters
Default
value
P05.09
HDI terminal function
8: Operation pause
9: External fault input
10: Increasing frequency setting (UP)
11: Decreasing frequency setting (DOWN)
12: Frequency setting clear
13: Shift between A setting and B setting
14: Shift between combination setting and A
setting
15: Shift between combination setting and B
setting
16: Multi-step speed terminal 1
17: Multi-step speed terminal 2
18: Multi-step speed terminal 3
19: Multi- step speed terminal 4
20: Multi- step speed pause
21: ACC/DEC time 1
22: ACC/DEC time 2
23: Simple PLC stop reset
24: Simple PLC pause
25: PID control pause
26: Limit of forward running
27: Limit of reverse running
28: Electronic gear selection
29: Torque control disabling
30: ACC/DEC disabling
31: Pulse ascending
32: Pulse descending
33: Cancel the frequency change setting
temporarily
34: DC brake
35: Shift the motor 1 into motor 2
36: Shift the command to the keypad
37: Shift the command to the terminals
38: Shift the command to the communication
39: Pre-magnetized command
40: Consumption power clear
41: Consumption power holding
42: Keypad setting of the torque upper limit
0
