Goodrive35 Series Closed-loop Vector Control VFD Extension card
245
Master station and VFD should be configured so that the master station can communicate with the
communication card after correctly installing EC-TX-103 communication card.
Each PROFIBUS subsidiary station on the PROFIBUS bus need to have "device description
document" named GSD file which used to describe the characteristics of PROFIBUS-DP devices.
The software we provided for the user includes VFD related GSD files (device data files) information,
users can obtain type definition file (GSD) of master machines from local INVT agent.
Configuration parameters of EC-TX-103 communication card:
Parameter number
Parameter name
Optional setting
Factory setting
0
Module type
Read only
PROFIBUS-DP
1
Node address
099
2
2
Baud rate setting
kbit/s
0: 9.6
6
1: 19.2
2: 45.45
3: 93.75
4: 187.5
5: 500
Mbit/s
6: 1.5
7: 3
8: 6
9: 9
10: 12
3
PZD3
065535
0
4
PZD4
The same as the
above
0
……
The same as the
above
0
10
PZD12
The same as the
above
0
2. Module type
This parameter shows communication module type detected by VFD; users can not adjust this
parameter. If this parameter is not defined, communication between the communication card and VFD
cannot be established.
3. Node address
In PROFIBUS network, each device corresponds to a unique node address, you can use the node
address selection switch to define node address (switch isn’t at 0) and the parameter is only used to
display the node address. If node address selection switch is 0, this parameter can define node
address.
