INVT Goodrive35 Series User Manual

Goodrive35 Series Closed-loop Vector Control VFD Installation guide
23
Figure 4-11 Terminals of main circuit for the VFDs of 380 V 7.5–11 kW
A1 A2
(+) P B (- ) R S T U V W
Figure 4-12 Terminals of main circuit for the VFDs of 380 V 15–18 kW
Figure 4-13 Terminals of main circuit for the VFDs of 380 V 22–30 kW
