SV-DA200 series AC servo drives Faults and solutions
‐94‐
[1] Analog input
The motor speed can be controlled by applying -10V~10V voltage
between analog speed input terminals (AD1, GND, pin “1” and “5”)
of CN1. In the factory default, the positive value means the forward
direction and the negative value means the reverse direction.
The direction of analog speed command can be changed by P0.41.
Please refer to the detailed instruction of P0.41.
2 Bus input
The speed command from upper PC can be received by the
interface of communication bus. When P4.10 is 1, the motor speed
can be changed by P4.13.
Please refer to the detailed instruction of P4.10 and P4.13.
3 Factory use -
4
2
nd
encoder
input
The speed is the speed calculated via P0.22 of 2
nd
encoder pulse.
5
High resolution
internal speed
High resolution internal speed, precision 0.1r/min
P0.40
Data size 16bit Data format DEC
Modbus address 1080,1081 CANopen address 0x2028, 0x00
P0.41
Setting of speed command
direction
Setting range Default Unit Available mode
0~1 0 - S
This parameter is used to set the forward/reverse direction when P0.40 is 0 and 1 and the
speed command sign is selected as S-SIGN.
Setting
value
Internal speed step/analog input Speed command sign
Speed command
direction
[0]
Positive speed 0V ~10V No use Forward direction
Negative speed -10V~0V No use Reverse direction
1
No use Valid Forward direction
No use Invalid Reverse direction
P0.41
Data size 16bit Data format DEC
Modbus address 1082,1083 CANopen address 0x2029, 0x00
P0.42 Analog input 1 gain
Setting range Default Unit Available mode
10~2000 100 (r/min)/V S
1. Suppose the analog input 1 function selection is speed command.
2. The voltage of the analog speed command input corresponds to the changing gain of the
motor command speed.
3. The relation between analog speed command input voltage and the speed, the default value
is that each 1V corresponds to 100r/min.
Analog speed command = Input voltage x P0.42
