INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐107‐
P1.24 1
st
notch filter Q value
Setting range Default Unit Available mode
0.50~16.00 1.00 - P S T F
This parameter is used to set the Q value (quality factor) of 1
st
notch filter
Q=Center frequency of 1
st
notch filter/bandwidth of the notch. Generally, this parameter should
remain in default value.
P1.24
Data size 16bit Data format DEC
Modbus address 1248,1249 CANopen address 0x2118,0x00
P1.25
1
st
notch filter depth
selection
Setting range Default Unit Available mode
0~100 0 % P S T F
This parameter is used to set the amplitude attenuation rate of 1
st
notch filter.
When the setting value increases, the notch filter depth becomes shallow and phase lag will be
smaller.
P1.25
Data size 16bit Data format DEC
Modbus address 1250,1251 CANopen address 0x2119,0x00
P1.26 2
nd
notch filter frequency
Setting range Default Unit Available mode
50~5000 5000 Hz P S T F
P1.27 2
nd
notch filter Q value
Setting range Default Unit Available mode
0.50~16.00 1.00 - P S T F
P1.28
2
nd
notch filter depth
selection
Setting range Default Unit Available mode
0~100 0 % P S T F
Refer to P1.23, P1.24 and P1.25 for detailed parameters setting.
P1.26
Data size 16bit Data format DEC
Modbus address 1252,1253 CANopen address 0x211A,0x00
P1.27
Data size 16bit Data format DEC
Modbus address 1254,1255 CANopen address 0x211B,0x00
P1.28
Data size 16bit Data format DEC
Modbus address 1256,1257 CANopen address 0x211C,0x00
P1.29 3
rd
notch filter frequency
Setting range Default Unit Available mode
50~5000 5000 Hz P S T F
P1.30 3
rd
notch filter Q value
Setting range Default Unit Available mode
0.50~16.00 1.00 - P S T F
P1.31
3
rd
notch filter depth
selection
Setting range Default Unit Available mode
0~100 0 % P S T F
Refer to P1.23, P1.24 and P1.25 for detailed parameters setting.
P1.29
Data size 16bit Data format DEC
Modbus address 1258,1259 CANopen address 0x211D,0x00
P1.30
Data size 16bit Data format DEC
Modbus address 1260,1261 CANopen address 0x211E,0x00
