INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐142‐
This parameter is used to set the regenerative brake mode and overload protection mode.
Setting value Regenerative brake and overload protection
[0] Disabled (no regenerative brake)
1 Embedded
2 External
P4.34
1
Data size 16bit Data format DEC
Modbus address 1868,1869 CANopen address 0x2422,0x00
P4.36
1
Undervoltage protection of
main power supply
Setting range Default Unit Available mode
0~1 1 - P S T F
This parameter is used to set whether the drive will report main circuit undervoltage alarm when
undervoltage occurs to the main power supply.
Setting value Protection
0 Do not display the undervoltage fault of the main circuit (Er13-1)
[1] Display the undervoltage fault of the main circuit (Er13-1) and stop
P4.36
1
Data size 16bit Data format DEC
Modbus address 1872,1873 CANopen address 0x2424,0x00
P4.37
Undervoltage detection time
of main power supply
Setting range Default Unit Available mode
70~2000 70 ms P S T F
This parameter is used to set the undervoltage detection time of the main power supply.
Note: The function is invalid if it is set to 2000.
P4.37
Data size 16bit Data format DEC
Modbus address 1874,1875 CANopen address 0x2425,0x00
P4.39 Speed deviation setting
Setting range Default Unit Available mode
0~20000 0 r/min P S F
This parameter is used to set the detection condition of the speed error. If the absolute value of
the minus of actual speed command and motor speed is larger than this value and lasts for more
than 100ms, it will report speed error alarm.
Note: If it is set to 0, the speed error will not be detected.
P4.39
Data size 16bit Data format DEC
Modbus address 1878,1879 CANopen address 0x2427,0x00
P4.40 Forward speed limit
Setting range Default Unit Available mode
0~20000 20000 r/min P S T F
This parameter is used to set the max. speed limit for forward speed command.
Note: The default value and setting range of the parameter is relative to the drive power level.
P4.40
Data size 16bit Data format DEC
Modbus address 1880,1881 CANopen address 0x2428,0x00
