INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Faults and solutions
‐203‐
R1.03
Original voltage of analog
input 2
Display range Precision Unit
-10.000~10.000 0.001 V
Display the original voltage value of analog input channel 2
R1.03
Data size 32bit Data format DEC
Modbus address 4206,4207 CANopen address 0x3103,0x00
R1.04
Original voltage of
analog input 3
Display range Precision Unit
-10.000~10.000 0.001 V
Display the original voltage value of analog input channel 3
R1.04
Data size 32bit Data format DEC
Modbus address 4208,4209 CANopen address 0x3104,0x00
R1.05 Voltage of analog input 1
Display range Precision Unit
-10.000~10.000 0.001 V
Display the calibrated voltage value of analog input channel 1.
R1.05
Data size 32bit Data format DEC
Modbus address 4210,4211 CANopen address 0x3105,0x00
R1.06 Voltage of analog input 2
Display range Precision Unit
-10.000~10.000 0.001 V
Display the calibrated voltage value of analog input channel 2
R1.06
Data size 32bit Data format DEC
Modbus address 4212,4213 CANopen address 0x3106,0x00
R1.07 Voltage of analog input 3
Display range Precision Unit
-10.000~10.000 0.001 V
Display the calibrated voltage value of analog input channel 3
R1.07
Data size 32bit Data format DEC
Modbus address 4214,4215 CANopen address 0x3107,0x00
R1.08 Voltage of analog output 1
Display range Precision Unit
-10.000~10.000 0.001 V
Display the output voltage value after offset treatment of analog output channel 1
R1.08
Data size 32bit Data format DEC
Modbus address 4216,4217 CANopen address 0x3108,0x00
R1.09 Voltage of analog output 2
Display range Precision Unit
-10.000~10.000 0.001 V
Display the output voltage value after offset treatment of analog output channel 2
R1.09
Data size 32bit Data format DEC
Modbus address 4218,4219 CANopen address 0x3109,0x00
