SV-DA200 series AC servo drives Communication
‐226‐
Display Fault name
32-bit fault code(16-bit Error
Code+16-bit additional message)
Er02-8 Encoder fault–Low voltage alarm of the encoder 7300-0208h
Er02-9 Encoder fault–Undervoltage alarm of the encoder 7300-0209h
Er02-a Encoder fault–Encoder over-temperature 7300-020Ah
Er02-b Encoder fault–EEPROM write error 7300-020Bh
Er02-c Encoder fault–EEPROM no data 7300-020Ch
Er02-d Encoder fault–EEPROM data check error 7300-020Dh
Er03-0 Current sensor fault–U phase IGBT fault 7300-0300h
Er03-1 Current sensor fault–V phase IGBT fault 7300-0301h
Er03-2 Current sensor fault–W phase IGBT fault 7300-0302h
Er04-0 System initialization fault FF01-0400h
Er05-1 Setting fault–Motor model error FF01-0501h
Er05-2 Setting fault–Motor and drive model error FF01-0502h
Er05-3 Setting fault–Software limit setting error FF01-0503h
Er05-4 Setting fault–Homing mode setting fault FF01-0504h
Er05-5 Setting fault–Position control overflow fault FF01-0505h
Er07-0 Regeneration discharge overload fault 7100-0700h
Er08-0 Analog input overvoltage fault–Analog input 2 5441-0800h
Er08-1 Analog input overvoltage fault–Analog input 3 5442-0801h
Er08-2 Analog input overvoltage fault–Analog input 3 5443-0802h
Er09-0 EEPROM fault–Read-write fault 5530-0900h
Er09-1 EEPROM fault–data check fault 5530-0901h
Er10-0 Hardware fault–FPGA fault 5544-0A00h
Er10-1 Hardware fault–Communication card fault 5544-0A01h
Er10-2 Hardware fault–Grounding short circuit fault 5544-0A02h
Er10-3 Hardware fault–External input fault 5544-0A03h
Er10-4 Hardware fault–Emergency stop fault 4458-0A04h
Er10-5 Hardware fault–485 communication fault 4458-0A05h
Er11-0 Software fault-Motor control task re-entry 6100-0B00h
Er11-1 Software fault–Reentrant cycle mission 6100-0B01h
Er11-2 Software fault–Illegal operation 6100-0B02h
Er12-0 IO fault–Repeat digital input distribution FF01-0C00h
Er12-1 IO fault-Repetitive analog input distribution FF01-0C01h
Er12-2 IO fault–Pulse input frequency is too high FF01-0C02h
Er13-0 Main circuit overvoltage fault 3110-0D00h
Er13-1 Main circuit undervoltage fault 3120-0D01h
Er14-0 Undervoltage control power fault 5200-0E00h
Er17-0 Drive overload fault FF01-1100h
