INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Appendix
‐254‐
Function
code
Name Unit Range Default
Available
Mode
P3.25
Voltage protection of analog
input 2
V 0.000~10.000 0.000 PSTF
P3.26
Function selection of analog
input 1
- 0~7 0 PSTF
P3.27
Function selection of analog
input 2
- 0~7 3 PSTF
P3.28
Analog speed compensation
gain
% 0.0~100.0 0.0 PSTF
P3.29
Analog torque compensation
gain
% 0.0~100.0 0.0 PSTF
P3.30
1
Analog output 1 selection - 0~19 0 PSTF
P3.31 Voltage gain of analog output 1 [P3.30 unit]/V 0~214748364 0 PSTF
P3.32
1
Analog output 2 selection - 0~19 0 PSTF
P3.33 Voltage gain of analog output 2 [P3.30 unit]/V 0~214748364 0 PSTF
P3.34 Offset voltage of analog output 1 V -10.000~10.000 0.000 PSTF
P3.35 Offset voltage of analog output 2 V -10.000~10.000 0.000 PSTF
P3.36
1
Analog output monitor setting - 0~2 0 PSTF
P3.40
1
Travel limit switch shield - 0~2 1 PSTF
P3.41
1
Emergency stop switch shield - 0~1 1 PSTF
P3.43
1
Digital input filter 0.125ms 1~800 1 PSTF
P3.44
Command pulse input invalid
setting disabled
- 0~1 0 PF
P3.45
1
Clearing mode of retention pulse - 0~1 1 PF
P3.50 Range of position arrival reference unit 0~2
18
100 PF
P3.51 Output mode of position arrival - 0~4 0 PF
P3.52
Hold time of position arrival
output terminal
ms 0~30000 0 PF
P3.53 Speed matching range r/min 10~20000 50 PSTF
P3.54 Speed reaching range r/min 10~20000 1000 PSTF
P3.55 Zero speed range r/min 10~20000 50 PSTF
P3.56
Locked time of servo after
braking
ms 0~1000 50 PSTF
P3.57
Braking delay of electromagnetic
brake
ms 0~30000 500 PSTF
P3.58
1
Motor speed of brake release r/min 0~1000 30 PSTF
P3.59 Torque reaching range % 5.0~300.0 50.0 T
P3.70
1
Function of analog input 3 - 0~7 4 PSTF
P3.71 Zero offset of analog input 3 V -10.000~10.000 0.000 PSTF
