INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Appendix
‐256‐
Function
code
Name Unit Range Default
Available
Mode
P4.30 Stop mode - 0~3 0 PSTF
P4.31 Max speed limit r/min 0~20000 5000 PSTF
P4.32 Overspeed level r/min 0~20000 6000 PSTF
P4.33 Pulse range of position deviation reference unit 0~2
27
100000 PF
P4.34
1
Brake overload detection
selection
- 0~2 0 PSTF
P4.36
1
Undervoltage protection of main
power supply
- 0~1 1 PSTF
P4.37
Undervoltage detection time of
main power supply
ms 70~2000 70 PSTF
P4.39 Speed deviation setting r/min 0~20000 0 PSF
P4.40 Forward speed limit r/min 0~20000 20000 PSTF
P4.41 Reverse speed limit r/min -20000~0 -20000 PSTF
P4.42 Internal speed of high resolution r/min
-20000.0~20000
.0
0.0 PSTF
P4.50
1
Offset of encoder Z phase pulse 0~(2
20
-1) 0 PSTF
P4.51 Switching time 1 of torque limit ms/100% 0~4000 0 PSF
P4.52 Switching time 2 of torque limit ms/100% 0~4000 0 PSF
P4.53
Current loop response
adjustment
% 10.0~200.0 100.0 PSTF
P4.54
1
Initialization time after power on ms 0~200000 0 PSTF
P4.60
1
Frequency division molecular of
external linear encoder
- 0~2
23
0 F
P4.61
1
Frequency division denominator
of external linear encoder
- 1~2
23
10000 F
P4.62
1
Direction reverse of external
linear encoder
- 0~1 0 F
P4.64
1
Large mixed deviation setting reference unit 0~2
27
160000 F
P4.65
1
Mixed deviation clearing r 0~100 0 F
P4.67
1
External linear encoder pulse
output mode of AB phase
- 0~1 0 F
P4.68
1
External linear encoder (2
nd
encoder) resolution
pulse 1~2
23
10000 PF
P4.69
1
Frequency division output
source
- 0~3 0 PSTF
P4.70
1
External linear encoder (2
nd
encoder) Z signal type
- 0~3 0 PSTF
P4.78
1
MotionNet node number - 0~63 0 PSTF
