INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Appendix
‐258‐
Function
code
Name Unit Range Default
Available
Mode
on
P5.12
1
st
speed setting of high speed
homing
r/min 0~2000 100 P
P5.13
2
nd
speed setting of high speed
homing
r/min 0~60 20 P
P5.14 Home setting reference unit -(2
31
-1)~(2
31
-1) 0 P
P5.15* Homing trigger command - 0~1 0 P
P5.16 Correlated action of homing - 0~3 0 P
P5.17
Speed to designated target after
homing
- 1~5000 0 P
P5.18
ACC/DEC time to designated
target after homing
r/min 0~32767 100 P
P5.19
Positon to designated target
after homing
reference unit -(2
31
-1)~(2
31
-1) 300 P
P5.20* PTP trigger command - -1~2048 -1 P
P5.21 00 target speed r/min 0~6000 20 P
P5.22 01 target speed r/min 0~6000 50 P
P5.23 02 target speed r/min 0~6000 100 P
P5.24 03 target speed r/min 0~6000 200 P
P5.25 04 target speed r/min 0~6000 300 P
P5.26 05 target speed r/min 0~6000 500 P
P5.27 06 target speed r/min 0~6000 600 P
P5.28 07 target speed r/min 0~6000 800 P
P5.29 08 target speed r/min 0~6000 1000 P
P5.30 09 target speed r/min 0~6000 1300 P
P5.31 10 target speed r/min 0~6000 1500 P
P5.32 11 target speed r/min 0~6000 1800 P
P5.33 12 target speed r/min 0~6000 2000 P
P5.34 13 target speed r/min 0~6000 2300 P
P5.35 14 target speed r/min 0~6000 2500 P
P5.36 15 target speed r/min 0~6000 3000 P
P5.37 00 ACC/DEC time ms 0~32767 200 P
P5.38 01 ACC/DEC time ms 0~32767 300 P
P5.39 02 ACC/DEC time ms 0~32767 500 P
P5.40 03 ACC/DEC time ms 0~32767 600 P
P5.41 04 ACC/DEC time ms 0~32767 800 P
P5.42 05 ACC/DEC time ms 0~32767 900 P
P5.43 06 ACC/DEC time ms 0~32767 1000 P
