INVT SV-DA200 User Manual

SV-DA200 series AC servo drives Appendix
‐259‐
Function
code
Name Unit Range Default
Available
Mode
P5.44 07 ACC/DEC time ms 0~32767 1200 P
P5.45 08 ACC/DEC time ms 0~32767 1500 P
P5.46 09 ACC/DEC time ms 0~32767 2000 P
P5.47 10 ACC/DEC time ms 0~32767 2500 P
P5.48 11 ACC/DEC time ms 0~32767 3000 P
P5.49 12 ACC/DEC time ms 0~32767 5000 P
P5.50 13 ACC/DEC time ms 0~32767 8000 P
P5.51 14 ACC/DEC time ms 0~32767 50 P
P5.52 15 ACC/DEC time ms 0~32767 30 P
P5.53 00 delay time ms 0~32767 0 P
P5.54 01 delay time ms 0~32767 100 P
P5.55 02 delay time ms 0~32767 200 P
P5.56 03 delay time ms 0~32767 400 P
P5.57 04 delay time ms 0~32767 500 P
P5.58 05 delay time ms 0~32767 800 P
P5.59 06 delay time ms 0~32767 1000 P
P5.60 07 delay time ms 0~32767 1500 P
P5.61 08 delay time ms 0~32767 2000 P
P5.62 09 delay time ms 0~32767 2500 P
P5.63 10 delay time ms 0~32767 3000 P
P5.64 11 delay time ms 0~32767 3500 P
P5.65 12 delay time ms 0~32767 4000 P
P5.66 13 delay time ms 0~32767 4500 P
P5.67 14 delay time ms 0~32767 5000 P
P5.68 15 delay time ms 0~32767 5500 P
P5.69 PTP trigger buffer switch - 0~1 0 P
P5.70 Single-turn resolution of disk pulse -(2
31
-1)~(2
31
-1) 10000 P
P5.71 Zero-returning switch of disk - 0~3 0 P
P5.72 Multi-turn mode - 0~1 0 P
P5.73 Digital trigger mode of PTP - 0~1 0 P
P5.74 Digital output mode of PTP - 0~4 0 P
P6 Application function
P6.00 Forward low JOG speed r/min 0~6000 5 P
P6.01 Reverse low JOG speed r/min -6000~0 -5 P
P6.02 Position latch function switch - 0~1 0 P
P6.03 Position latch save mode - 0~1 0 P
P6.04 Forward high JOG speed r/min 0~6000 60 P
