SV-DA200 series AC servo drives Control mode applications
‐50‐
Signal name Sign Function number Available mode
control mode, it has the same function with P5.20 when it is 100.
Signal name Sign Function number Available mode
Absolute position clearing PCLR 0x1F P
This function is used to clear the multi-turn absolute encoder.
When this digital input is valid, the multi-turn data of the encoder will be cleared while the single-turn
data remains unchanged, however, the absolute position feedback of the system will be cleared.
Signal name Sign Function number Available mode
Forward jogging FJOG 0x23 P
This function is forward jogging. When this digital input is valid, forward jogging operation will be applied.
Signal name Sign Function number Available mode
Reverse jogging RJOG 0x24 P
This function is reverse jogging. When this value is valid, reverse jogging operation will be applied.
Signal name Sign Function number Available mode
High/low speed switching of jogging JOGC 0x25 P
This function is high/low speed switching of jogging. When this digital input is valid, high speed
jogging will be applied.
Signal name Sign Function number Available mode
JOG function of the terminal DJOG 0x2C P
When this digital input is valid, JOG function of the terminal is valid.
Signal name Sign Function number Available mode
Gantry synchronization input clear GIN 0x2D P
When this digital input is valid, gantry synchronous is removed.
Signal name Sign Function number Available mode
Master gantry synchronization alignment sensor GSM 0x2E P
Master gantry synchronization alignment sensor
Signal name Sign Function number Available mode
Slave gantry synchronization alignment sensor GSS 0x2F P
Slave gantry synchronization alignment sensor
Signal name Sign Function number Available mode
Dynamic braking relay feedback DBS 0x30 P S T F
When this digital input is valid, the dynamic braking relay will be closed.
Signal name Sign Function number Available mode
Manual and automatic switching of turret DAT 0x31 P
