9.5 Data Me
• T
• T .
• The stri
• The first line contains the structur version. (‘V’nn) nn = 2 Dezimalzahlen
• This document describes the structurversion 1.
[Version]
1
ssage Format
he UDP-Data message contains ASCII coded lines.
he lines space is \n\r (0x0A 0x0D)
ng 0 is time-phased.
[ID]
MessageNumer
[Pattern]
000000
[RS232]
RX=646E
TX=0FFF
[Counter]
00000000
00000000
00000000
00000000
00000000
00000000
[Events]
EventNumber ; Pin; State
EventNumber ; Pin; State
EventNumber ; Pin; State
EventNumber ; Pin; State
EventNumber ; Pin; State
EventNumber ; Pin; State
…
MessageNumber
A 4 digit Hex number. Every UDP Message increase this number. it starts from
0 to 0..FFFF and repeat with 0. With every number you can find a lost
message.Eine ge Hex Nummer. 4-stelli
EventNumber
Every event gets a event number. This number starts from 0 to 0xFF and
repeat with 0. This number you can detect every lost event.
Pin
The Pin number from which one the event came. Values from 0 to 5.
State
The State: 0=off / 1 = on
RX
Free bytes on the reception memory
TX
Free bytes on the transmission memory
Pattern
the current PIN – input model (eingangsmuster) (6 Bits binär)
Latest 50 Events
